CL202PH16 - Trailer 2 axles Pintle Hook 20K Capacity -

CL202PH16 & CL202GN16 Cam-Lift, 2 axles, 20 000 lbs. capacity, 16-foot deck, (Payload includes the container’s weight)
Trailer specs:

• Two axles Heavy Duty Dexter 10 000 lbs. capacity each
• Pintle hook: Empty weight 6,996 lbs. (approx.)
• Payload 13,004 lbs.+ 5,758 lbs. load on the truck = 18,762 lbs.
• Hook lifting capacity 24 000 lbs. @ 3000 psi
• Hook Height 54”
• Heavy duty frame
• Goose neck attachment
• 4 x 16 ply tires and 17 ½ ’’ galvanized steel rims
• Electric brakes
• Aluminum fenders
• 5’’ hydraulic cylinders for loading and dumping
• 3’’ hydraulic cylinder for the Tilt
• Deposit or dump selection from the truck, Dumping angle up to 50°
• Hydraulic Power unit with 13 HP gas engine @ 3100 Psi with 6 GPM Pump installed on the trailer with 10 or 14-gallon tank
• Manifold bloc valve 12 volts on the trailer
• Wireless remote control with manual control on the trailer
• 12 000lb drop leg jack
• All lights DEL
• Epoxy Primer
• Choice of Color for the paint.










Build time 5 to 7 weeks, this time of estimation is depending of various others factors, like third party supplier and work load.

We Require 50% deposit on all orders; this quotation is valid for 30days

Shipping cost and taxes are not included

Financing available
